0、dual-head print on dual sides:Select to print same or different content;

     printing different sides allows text to be visible on all sides;

     dual-head print on same side:Select to print same or different content;

     printing the same side can speed up the marking process;

1、Guarantee 0.05% meter  accuracy by Real‑time waveform correction；

2、Max linespeed：

                       550 m/min (Print full‑content & Meter;  2 group content per meter)，

                      1000 m/min (Only Print Cable No. as Single machine operation)；

                      1400 m/min (Only Print Cable No. as Dual machine operation)；

                      1500 m/min (Only Print meter)；

3、Better printing color:Because linespeed increased by 70%,we can use lower

      scan-speed for the original production line to achieve better printing color ;

4、Longer lifetime:Because linespeed increased by 70%,we can use lower laser-power

      for the original production line to achieve longer lifetime ;

5、Extra‑large control screen, built‑in MES system,

     compatible with any Sys. to avoid marking errors；

6、Built‑in early‑warning function for advance prediction and error prevention；

7、Early detection & correction for insufficient remaining length at cable end；

8、Free software service；

9、It can be equipped with a self-developed stroboscope, which automatically matches the parameters of the stroboscope to achieve visual display of printed content on high-speed production lines;

10、Super anti-interference ability, spark machine interference does not affect coding and meter counting;

11、Meet the requirements of fully automated formulaic production

Production line with linespeed of ≤ 1500 mpm

550 m/min (Print full‑content & Meter;  2 group content per meter)，

1000 m/min (Only Print Cable No. as Single machine operation)；

1400 m/min (Only Print Cable No. as Dual machine operation)；

1500 m/min (Only Print meter)；
